7 Color Series Triple Gauge Package for 2014-2019 Chevrolet Silverado Duramax

GlowShift's 7 Color Series Triple Gauge Package was made for the 2014-2019 Chevrolet Silverado 2500HD/3500HD with a 6.6L Duramax Turbo Diesel LML or L5P engine. Experience complete customization when you select from over 20 gauges for this 3-gauge set which comes with all required sensors. This package also includes your choice of a tan or black full-size Silverado triple pillar pod that replaces the factory A-pillar. With GlowShift’s 7 Color Gauge Series, you’ll experience the option of 7 different colors featured on an ultra-bright LED analog gauge display.

Gauge Series Details

A wide variety of unique color and style settings are available for complete customization of your ultra high-performance 2-1/16” (52mm) gauges. Choose from a black or white gauge face, and utilize 7 ultra-bright solid color display options that will allow you to match the lighting display of your Silverado’s factory dashboard. These gauges also include microprocessor controlled stepper motor technology, selectable 7 color LED through dial lighting, a magnified tinted or clear lens depending on your selection, and an illuminated red needle that sweeps 270°. GlowShift also includes all sensors, wiring, mounting hardware and a one-year limited warranty with each purchase.

7 Color Gauge Series Choose from Black, White or Tinted Series Black or White Gauge Face Clear or Tinted Magnified Lens Ultra-Bright Analog LED Display Stepper Motor Technology

Match Your Factory Dash Lights 7 Color LED Through Dial Lighting 7 Solid Color Settings Blue, Red, Green, Teal, Purple, White & Yellow Two Color Cycle Modes Remembers Last Color Setting

Nighttime Dimming Dimmer Wire Dims Gauge 30% Reduce Brightness When Driving at Night Continue to Easily View your Readings Works When your Headlights are Turned On Activate with a Simple Connection

Diesel Tech Picks

Our Diesel Techs have years of experience and a wealth of knowledge when it comes to choosing the gauges that will work best for your Chevy Silverado Duramax. Here you’ll find their top choices based on performance, efficiency, reliability, and how effective these gauges will be in providing you with all of the information you need to get the best performance out of your truck.

60 PSI Boost Reads Boost from 0 - 60 PSI 9' of Nylon Hose 1/8-27 NPT Brass Compression Fittings Mechanically Driven

1500° F Pyrometer EGT Reads Exhaust Temperature from 0 - 1500° Fahrenheit 1/8-27 NPT EGT Probe with 3' of Steel Braided Cable 6' Sensor & 2' Power Wire Harnesses Waterproof EGT Probe to Sensor Harness Connector

Transmission Temperature Reads Transmission Temperature from 80 - 260° Fahrenheit 1/8-27 NPT Electronic Temperature Sensor 2' Sensor & Power Wire Harnesses Recommended For Vehicles with Automatic Transmission

30 PSI Fuel Pressure Reads Fuel Pressure from 0 - 30 PSI 1/8-27 NPT Electronic Fuel Pressure Sensor 9' Sensor & 2' Power Wire Harnesses Aftermarket Lift Pump is Required for Gauge to Work Properly

Pillar Pod Details

The included full size, factory matched triple pillar pod is made specifically for the 2014-2019 Chevrolet Silverado 2500HD/3500HD with a 6.6L Duramax Turbo Diesel LML or L5P engine. This tan or black pillar pod can be effectively mounted in place of your factory A-pillar for a custom fit and factory look, and holds (3) 2-1/16” (52mm) gauges. It is also crafted from high quality ABS plastic, allowing it to withstand cracking, fading and warping. The tan pod features a UV protective coating that preserves the color from exposure to sunlight so that it always matches the factory trim of the truck. The black pod can be painted using ABS plastic paint for a fully custom fit and finish. Fits: 14, 15, 16, 17, 18, 19 Chevrolet Silverado 1500, 2500HD & 3500HD.

Holds (3) 2-1/16” (52mm) Gauges Tan or Black Triple Pillar Pod Made from ABS Plastic Withstands Cracking, Fading and Warping

Replacement of Factory A-Pillar Full Length Gauge Pod Match to Your Factory Interior Professional Fit and Finish

Bolt Included for Pod Installation Installs Through Pre-Drilled Hole on Pod Easily Mounts to Factory Location No Drilling Required

Fitment Details

1/8-27 NPT Drill & Tap Set Used for Installing EGT Probe, Boost Fittings or Boost Sensor Drill & Tap Exhaust or Intake Manifold to 1/8-27 NPT Includes Size R Drill Bit & 1/8 NPT Tap	MAP Line T-Fitting Adapter Quick & Easy Install of Boost Hose or Sensor into the 3/16” MAP Line Cut the Line, Insert the T-Fitting & Secure with Included Clamps Avoid Drilling & Tapping the Intake Manifold Female 1/8-27 NPT Thread for Fittings/Sensor	Test Port Adapter for GM Allison 1000 Quick & Easy Install of Temperature Sensor to Transmission Test Port Threads onto Temperature Sensor for Protection from Internal Transmission Parts Includes O-Ring for Leak-Free Seal No Modifications to Transmission Necessary Female 1/8-27 NPT Thread for Sensor Fits 2000-2018 Chevy Silverado/GMC Sierra	Transmission Cooler Line T-Fitting Adapter for GM Allison 1000 Allows Installation of Temperature Sensor to the 5/8” Transmission Cooler Line Includes T-Fitting, Compression Nuts & Cutting Rings for Leak-Free Seal Female 1/8-27 NPT Thread on T-Fitting for Sensor Fits 2000-2019 Chevy Silverado/GMC Sierra
3/8” Quick-Connect EFI Fuel Line Adapter Easy Install of Fuel Pressure Sensor Between Fuel Line & Fuel Rail Compatible with 3/8” Modern Electronic Fuel Injection Lines No Need to Cut Factory Fuel Lines Features 2 Female 1/8-27 NPT Threads Features Internal O-Ring for Leak-Free Seal	18ft Pressure Sensor Harness Extends the Length of 9’ Harness Included with Gauge to 18’ Commonly Used on Trucks with Aftermarket Lift Pump Installed Plug & Play	Fuel Filter Bleeder Screw Upgrades the Factory Plastic Bleeder Screw to Durable Billet Aluminum Machined Air Channel Helps “Bleed” Air Out of the Fuel System Diesel Fuel Rated Viton O-Ring Provides a Leak-Free Seal Fits 2001-2016 6.6L Duramax LB7, LLY, LBZ, LMM & LML	Expandable Circuit Quick & Easy Way to Power Gauges Directly from the Fuse Panel Includes (2) Micro2 & (1) Mini Expandable Circuits Used for Constant & Switched 12 Volt Power for Gauges Mini Expandable Circuit Used for Dimming Feature Includes 4 & 5 Amp Fuses for Circuit Protection Bundled Specifically for 2014-2019 Chevrolet Silverado & GMC Sierra Trucks
3 Gauge Wiring Kit - Power Wires Only Conveniently Connect all Gauge Power Wires to 1 Easy-to-Use Wire Harness Color Matched Wires Make it Easy When Routing & Connecting Wires to their Source Extends the Length of Power Wires Included with Gauges Optional for Installation 6’ of Power/Ground Wires – Red, Yellow, Orange & Black Wires Compatible with 7 Color Gauge Series 20 Gauge Automotive Grade Wiring	3 Gauge Wiring Kit - Power & Sensor Wires Conveniently Connect all Gauge Power & Sensor Wires to 1 Easy-to-Use Wire Harness Color Matched Wires Make it Easy When Routing & Connecting Wires to their Source Extends the Length of Power/Sensor Wires Included with Gauges Optional for Installation 3’ of Power/Ground Wires – Red, Yellow, Orange & Black Wires 8’ of Sensor Wires – Blue, Brown & Green Wires Compatible with 7 Color Gauge Series 20 Gauge Automotive Grade Wiring

Installation Guides

This 7 Color Series Triple Gauge Package comes with an installation guide which is available online and in print and was made specifically for the 2014-2019 Chevrolet Silverado 2500HD/3500HD with a 6.6L Duramax Turbo Diesel LML or L5P engine. An installation video is also available which provides a complete step-by-step tutorial along with useful tips on how to install this gauge package.

Watch the Installation Video

Download and Print the PDF
